HCR POLARIS RZR PRO XP DUAL SPORT LONG TRAVEL SUSPENSION KIT

The Long Travel Suspension Kit has been re-envisioned to their new design platform and styling that offers sleek approach angles, a rigid look and added clearance. These added clearances can be noticed in the Front A-arms adding 1.25” under the Lower A-arm arch area and 3” of ground clearance added in the Rear Trailing Arm.
This new Long-Travel Suspension kit offers consumers the benefit of a little extra travel and stability with the +4” per sidetrack width. Embedded in the design is OEM caster / camber angles to eliminate the need for adjustable heim ends which provides a stronger mount for the arms pivot points.

Features

• +4 inches wider per side; Additional 8 inches of track width
• Fiber Laser Cut construction for precise fit and finish
• CNC'd 4130 heat treated billet mounting points for increased integrity
• Angled catacomb design for optimal force distribution
• High Clearance Boxed A-Arm Design
• Hand TIG welded for strength and aesthetics
• OEM ball joints are reused to maximize low speed steering, ease & smooth travel with less maintenance
• Compatible with factory wheels
• High-Clearance Arms provide 1.25” of front and 3” rear added ground clearance
• 100% Bolt-on installation using factory mounting points

Kit includes:

• 4 Front A-arms
• 2 Rear Trailing arms
• 4 Complete Nitro Axles
• Radius Rods
• Radius Rod Back Plate
• Hardware Pack

VEHICLE FITMENT:

• POLARIS RZR PRO XP : 2020+
• POLARIS RZR PRO XP 4 : 2020+
